• 24h 100% seal test guaranteed
• Dual sealing system allows valve to be operated in either direction making installation easier
• No metal-to-metal moving parts
• No maintenance ever required
• Handle clearly shows ball position
• Silicone-free lubricant on all seals
• Handle stops on body to avoid stress at stem
• Chrome plated DZR brass ball for longer life

• Full port to DIN 3357 for maximum flow

• Hot forged sand blasted DZR unplated body and cap sealed with Loctite® or equivalent thread sealant
• Dezincification resistant ADZ-T and ADZ-P brass approved to SBN-PFS 1983:2 and NR-BFS 1988:18 specifications
• Extended stem forged in one piece with body allows perfect sealing and easy operation when valve is isolated

• Geomet® carbon steel handle with thick PVC dip coating. Handle coating offers both thermal and electrical protection
• Handle removable with valve in service
• WARNING: do not exceed reasonable temperature and/or electrical load

• Maintenance-free, double FPM O-rings at the stem for maximum safety
• Unplated DZR brass stem

• 16 bar (230 PSI) non-shock cold working pressure
• -20°C to +120°C (-4°F to +250°F)
• WARNING: freezing of the fluid in the installation may severely damage the valve

• Pure PTFE self-lubricating seats with flexible-lip design

• T-handle
• Oval lockable handle
• Stainless steel handle (1.4016 / AISI 430)
• Patented locking device
• Short stem design
• Stubby handle
• RuB memory stop designed to be installed with our stubby handle

• Compression ends to EN 1254-2 and NKB no.12

• Stainless steel ball (1.4401 / AISI 316)
• Glass filled PTFE seals
• Custom design

• The product described in this document meets the requirements of the PED Directive 2014/68/UE and according to art.4 par.3, it does not require CE marking; it cannot be used with dangerous gases in sizes larger than 25 mm

• Kiwa-Swedcert (Sweden)
• GOST-R (Russia)
• RoHS Compliant (EU)

NOTE: approvals apply to specific configurations/sizes only.
